Which probes can I use with my PosiTector device?

The PosiTector exists in 2 versions:

• Standard: statistics, recording up to 1000 measurements in 1 single batch
• Advanced: statistics, recording up to 250,000 measurements in a maximum of 1000 batches, bluetooth and wifi functions

The detailed characteristics differ slightly depending on the type of probe connected (refer to the documentation for the detailed characteristics)

The PosiTector allows you to connect different types of probes:

• Coating thickness measurement on metal supports: PosiTector 6000 probes

• Coating thickness measurement on non-metallic substrates: PosiTector 200 probes

• Wall thickness measurement: PosiTector UTG probes

• Temperature, hygrometry, dew point measurement: PosiTector DPM probes

• Concrete moisture measurement: PosiTector CCM IS

• Infrared temperature measurement: PosiTector IRT

• Profile depth measurement: PosiTector SPG probes

• Press O film tape measurement: PosiTector RTR probes

• Measurement of soluble salts: PosiTector SST

• Shore hardness measurement: PosiTector SHD

• Barcol hardness measurement: PosiTector BHI

These different models are presented in detail on our site with the associated documentation.

You will also find in the attached documents a detailed list of probe / box compatibilities.

Your new probe is not recognized by the device? Consider updating your device: POSITECTOR UPDATE

How do I retrieve my measurements?

DEFELSKO offers various software solutions compatible with Positector, smartlink or Positest AT measuring devices

- PosiSoft desktop : Powerful desktop software for downloading, viewing, printing and storing measurement data. No internet connection required. Simple and intuitive user interface. Import measurements directly from device via USB or from older PosiSoft desktop versions, synchronize measurement data including readings, notes and images to and from PosiSoft.net

- PosiSoft.net : The intuitive and familiar user interface of PosiSoft Desktop is integrated into your web browser. The data is stored securely in the cloud.

- Application PosiTector : An easy to use mobile application (iOS / Android) that connects to your PosiTector Advanced, PosiTector Smartlink or PosiTest AT.

- PosiSoft USB : A simple gauge interface to recover data in a manner similar to a flash drive. No software to install or internet connection required

- Resources for PosiTecto developersA: From wired USB technology to WiFi wireless technology, DeFelsko instruments offer data management solutions for the most advanced software integrations. Accessing your stored or live streamed data is easier and more flexible than ever. The PosiTector and PosiTest AT-A instruments have the ability to integrate with third-party software, drones, ROVs, APIs, and robotic devices using multiple standard communication protocols. Learn more about integrating third-party devices and applications.

Access the DEFELSKO software solutions download area

:
